Üç Yollu Küresel Vana A

Hidrolik sektörünün önemli demirbaşlarından olan Küresel Vanalar ve İğne Vanaların satışını yapmaktayız. Küresel Vanalar ve İğne Vanalar kategorisi altında küresel vana, iğne vana, silindirik vana gibi aradığınız birçok paslanmaz bağlantı elemanları bizden temin edebilirsiniz. Hidrolik bağlantı elemanlarını paslanmaz çelikten 1.4571 (AISI 316Ti) üretmekteyiz. Özelliği 316Ti ve 316L olan parçalarımız yüksek basınç ve sıcaklığa dayanıklıdır. Aradığınız ürünün detaylı bilgilerine ürün tablolarından ulaşabilirsiniz.

SheetJS Table Export

Boru / Pipe / Rohr	BasÄ±nc / Pressure / Druck	Dis / Thread / Gewinde	Olculer / Measurements / Ca. MaÃe													Urun Kodu / Product Code / Artikelnummer	Fiyat / Price
DN	PB	D	B	H	H1	H2	H4	i	L	L1	L10	LW	M	SW	SW Ã¸	Urun Kodu / Product Code / Artikelnummer	Fiyat / Price
4	100	G 1/8"	40	46.5	35	8	16	9	69	35	26	5	M 5	22	9	BK3-1/8"-4445-L	*
6	100	G 1/4"	40	46.5	35	8	16	12	69	35	26	6	M 5	22	9	BK3-1/4"-4445-L	*
10	100	G 3/8"	45	51.5	40	8	18	12	73	42	28	9	M 5	27	9	BK3-3/8"-4445-L	*
13	100	G 1/2"	50	56	40	8	17	14	85	47	32	11.5	M 5	30	9	BK3-1/2"-4445-L	*
20	100	G 3/4"	65	73.5	57	12	24.5	17	96	61	40.5	18	M 6	41	14	BK3-3/4"-4445-L	*
25	100	G 1"	80	81.5	65	12	30	19	113	63	51	22	M 6	46	14	BK3-1"-4445-L	*
32	100	G 1 1/4"	100	99	80	13.5	38	20	110	78	62	30	M 8	60	17	BK3-1 1/4"-4445-L	*
40	100	G 1 1/2"	105	109	90	13.5	42	24	120	85	65	35	M 8	70	17	BK3-1 1/2"-4445-L	*
50	100	G 2"	120	139	120	13.5	62	28	140	100	72	44	M 8	85	17	BK3-2"-4445-L	*

4	400	G 1/8"	40	46.5	35	8	16	9	69	35	26	5	M 5	22	9	BK3-1/8"-4423-LA	*
6	400	G 1/4"	40	46.5	35	8	16	12	69	35	26	6	M 5	22	9	BK3-1/4"-4423-LA	324.00
10	400	G 3/8"	45	51.5	40	8	18	12	73	42	28	9	M 5	27	9	BK3-3/8"-4423-LA	345.60
13	400	G 1/2"	50	56	40	8	17	14	85	47	32	11.5	M 5	30	9	BK3-1/2"-4423-LA	373.85
20	320	G 3/4"	65	73.5	57	12	24.5	17	96	61	40.5	18	M 6	41	14	BK3-3/4"-4423-LA	578.20
25	350	G 1"	80	81.5	65	12	30	19	113	63	51	22	M 6	46	14	BK3-1"-4423-LA	639.70
32	350	G 1 1/4"	100	99	80	13.5	38	20	110	78	62	30	M 8	60	17	BK3-1 1/4"-4423-LA	1,254.45
40	250	G 1 1/2"	105	109	90	13.5	42	24	120	85	65	35	M 8	70	17	BK3-1 1/2"-4423-TA	1,415.65
50	250	G 2"	120	139	120	13.5	62	28	140	100	72	44	M 8	85	17	BK3-2"-4423-LA	*

4	100	1/8"-27 NPT	40	46.5	35	8	16	12	69	35	26	5	M 5	22	9	BK3-1/8"-NPT-4445-L	*
6	100	1/4"-18 NPT	40	46.5	35	8	16	17	69	35	26	6	M 5	22	9	BK3-1/4"-NPT-4445-L	*
10	100	3/8"-18 NPT	45	51.5	40	8	18	17	73	42	28	9	M 5	27	9	BK3-3/8"-NPT-4445-L	*
13	100	1/2"-14 NPT	50	56	40	8	17	22	92	47	32	11.5	M 5	30	9	BK3-1/2"-NPT-4445-L	*
20	100	3/4"-14 NPT	65	73.5	57	12	24.5	23	97	61	40.5	18	M 6	41	14	BK3-3/4"-NPT-4445-L	*
25	100	1"-11,5 NPT	80	81.5	65	12	30	27	113	63	51	22	M 6	46	14	BK3-1"-NPT-4445-L	*
32	100	1 1/4"-11,5 NPT	100	99	80	13.5	38	28	115	78	62	30	M 8	60	17	BK3-1 1/4"-NPT-4445-L	*
40	100	1 1/2"-11,5 NPT	105	109	90	13.5	42	28	138	85	65	35	M 8	70	17	BK3-1 1/2"-NPT-4445-L	*
50	100	2"-11,5 NPT	120	139	120	13.5	62	30	140	100	72	44	M 8	85	17	BK3-2"-NPT-4445-L	*

4	400	1/8"-27 NPT	40	46.5	35	8	16	12	69	35	26	5	M 5	22	9	BK3-1/8"-NPT-4423-LA	*
6	400	1/4"-18 NPT	40	46.5	35	8	16	17	69	35	26	6	M 5	22	9	BK3-1/4"-NPT-4423-LA	*
10	400	3/8"-18 NPT	45	51.5	40	8	18	17	73	42	28	9	M 5	27	9	BK3-3/8"-NPT-4423-LA	*
13	400	1/2"-14 NPT	50	56	40	8	17	22	92	47	32	11.5	M 5	30	9	BK3-1/2"-NPT-4423-LA	*
20	320	3/4"-14 NPT	65	73.5	57	12	24.5	23	97	61	40.5	18	M 6	41	14	BK3-3/4"-NPT-4423-LA	*
25	350	1"-11,5 NPT	80	81.5	65	12	30	27	113	63	51	22	M 6	46	14	BK3-1"-NPT-4423-LA	*
32	350	1 1/4"-11,5 NPT	100	99	80	13.5	38	28	115	78	62	30	M 8	60	17	BK3-1 1/4"-NPT-4423-LA	*
40	250	1 1/2"-11,5 NPT	105	109	90	13.5	42	28	138	85	65	35	M 8	70	17	BK3-1 1/2"-NPT-4423-LA	*
50	250	2"-11,5 NPT	120	139	120	13.5	62	30	140	100	72	44	M 8	85	17	BK3-2"-NPT-4423-LA	*

4	100	M 12 x 1,5	40	46.5	35	8	16	10	67	35	41.5	5	M 5	6	22	BK3-6-L-4445-L	*
6	100	M 14 x 1,5	40	46.5	35	8	16	10	67	35	41.5	6	M 5	8	22	BK3-8-L-4445-L	*
8	100	M 16 x 1,5	40	46.5	35	8	16	11	71	35	41.5	7	M 5	10	22	BK3-10-L-4445-L	*
10	100	M 18 x 1,5	45	51.5	40	8	18	11	75	42	44.5	9	M 5	12	27	BK3-12-L-4445-L	*
13	100	M 22 x 1,5	50	56	40	8	17	12	84	47	50	11.5	M 5	15	30	BK3-15-L-4445-L	*
13	100	M 26 x 1,5	50	56	40	8	17	12	84	47	50	11.5	M 5	18	32	BK3-18-L-4445-L	*
20	100	M 30 x 2	65	73.5	57	12	24.5	14	102	61	60.5	18	M 6	22	41	BK3-22-L-4445-L	*
25	100	M 36 x 2	80	81.5	65	12	30	14	108	63	72	18	M 6	28	46	BK3-28-L-4445-L	*
32	100	M 45 x 2	100	99	80	13.5	38	16	128	78	86	30	M 8	35	60	BK3-35-L-4445-L	*
40	100	M 52 x 2	105	109	90	13.5	42	16	133	85	89	35	M 8	42	70	BK3-42-L-4445-L	*

4	400	M 12 x 1,5	40	46.5	35	8	16	10	67	35	41.5	5	M 5	6	22	BK3-6-L-4423-LA	*
6	400	M 14 x 1,5	40	46.5	35	8	16	10	67	35	41.5	6	M 5	8	22	BK3-8-L-4423-LA	*
8	400	M 16 x 1,5	40	46.5	35	8	16	11	71	35	41.5	7	M 5	10	22	BK3-10-L-4423-LA	*
10	400	M 18 x 1,5	45	51.5	40	8	18	11	75	42	44.5	9	M 5	12	27	BK3-12-L-4423-LA	*
13	400	M 22 x 1,5	50	56	40	8	17	12	84	47	50	11.5	M 5	15	30	BK3-15-L-4423-LA	*
13	400	M 26 x 1,5	50	56	40	8	17	12	84	47	50	11.5	M 5	18	32	BK3-18-L-4423-LA	*
20	320	M 30 x 2	65	73.5	57	12	24.5	14	102	61	60.5	18	M 6	22	41	BK3-22-L-4423-LA	*
25	350	M 36 x 2	80	81.5	65	12	30	14	108	63	72	18	M 6	28	46	BK3-28-L-4423-LA	*
32	350	M 45 x 2	100	99	80	13.5	38	16	128	78	86	30	M 8	35	60	BK3-35-L-4423-LA	*
40	250	M 52 x 2	105	109	90	13.5	42	16	133	85	89	35	M 8	42	70	BK3-42-L-4423-LA	*

4	100	M 14 x 1,5	40	46.5	35	8	16			35		5	M 5	6		BK3-6-S-4445-L	*
4	100	M 16 x 1,5	40	46.5	35	8	16	12	73	35	44.5	5	M 5	8	22	BK3-8-S-4445-L	*
6	100	M 18 x 1,5	40	46.5	35	8	16	12	73	35	44.5	6	M 5	10	22	BK3-10-S-4445-L	*
8	100	M 20 x 1,5	40	46.5	35	8	16	12	77	35	46	7	M 5	12	22	BK3-12-S-4445-L	*
10	100	M 22 x 1,5	45	51.5	40	8	18	14	84	42	48.5	9	M 5	14	27	BK3-14-S-4445-L	*
13	100	M 24 x 1,5	50	56	40	8	17	14	87	47	51.5	11.5	M 5	16	30	BK3-16-S-4445-L	*
13	100	M 30 x 2	50	56	40	8	17	16	91	47	51.5	11.5	M 5	20	32	BK3-20-S-4445-L	*
20	100	M 36 x 2	65	73.5	57	12	24.5	18	110	61	64.5	18	M 6	25	41	BK3-25-S-4445-L	*
25	100	M 42 x 2	80	81.5	65	12	30	20	120	63	78	22	M 6	30	46	BK3-30-S-4445-L	*
32	100	M 52 x 2	100	99	80	13.5	38	22	140	78	92	30	M 8	38	60	BK3-38-S-4445-L	*

4	400	M 14 x 1,5	40	46.5	35	8	16			35		5	M 5	6		BK3-6-S-4423-LA	*
4	400	M 16 x 1,5	40	46.5	35	8	16	12	73	35	44.5	5	M 5	8	22	BK3-8-S-4423-LA	*
6	400	M 18 x 1,5	40	46.5	35	8	16	12	73	35	44.5	6	M 5	10	22	BK3-10-S-4423-LA	*
8	400	M 20 x 1,5	40	46.5	35	8	16	12	77	35	46	7	M 5	12	22	BK3-12-S-4423-LA	*
10	400	M 22 x 1,5	45	51.5	40	8	18	14	84	42	48.5	9	M 5	14	27	BK3-14-S-4423-LA	*
13	400	M 24 x 1,5	50	56	40	8	17	14	87	47	51.5	11.5	M 5	16	30	BK3-16-S-4423-LA	*
13	400	M 30 x 2	50	56	40	8	17	16	91	47	51.5	11.5	M 5	20	32	BK3-20-S-4423-LA	*
20	320	M 36 x 2	65	73.5	57	12	24.5	18	110	61	64.5	18	M 6	25	41	BK3-25-S-4423-LA	*
25	350	M 42 x 2	80	81.5	65	12	30	20	120	63	78	22	M 6	30	46	BK3-30-S-4423-LA	*
32	350	M 52 x 2	100	99	80	13.5	38	22	140	78	92	30	M 8	38	60	BK3-38-S-4423-LA	*
